Description
The DJI Agras T70P is a professional agricultural drone platform designed for high-capacity spraying, spreading and specialized lifting operations.
The aircraft features a 70 L spraying tank. Its standard two-sprinkler configuration supports flow rates of up to 30 L/min, while the optional four-sprinkler configuration increases maximum flow to up to 40 L/min.
For granular applications, the T70P supports a 100 L spreading system with a maximum spreading payload of up to 70 kg. An optional lifting system supports payloads of up to 65 kg.
DJI Safety System 3.0 combines millimeter-wave radar and a Tri-Vision system to improve obstacle sensing, terrain awareness and intelligent route selection.
RTK positioning supports centimeter-level accuracy for precise field boundaries and repeatable agricultural missions. A maximum operating speed of up to 20 m/s helps increase productivity across large fields.
The DJI Agras T70P is suited to large U.S. farms, commercial application businesses, orchards, vineyards and demanding specialty agricultural operations.
Battery, charging and optional application systems depend on the selected package and should be confirmed before purchase.
FAQ
Question: What is the spraying capacity of the DJI Agras T70P?
Answer: The DJI Agras T70P features a 70 L spraying tank.
Question: What is the maximum spray flow rate?
Answer: The standard dual-sprinkler system supports up to 30 L/min. An optional four-sprinkler configuration can increase flow to up to 40 L/min.
Question: Can the DJI Agras T70P be used for spreading?
Answer: Yes. The T70P supports a 100 L spreading system with a maximum spreading payload of up to 70 kg.
Question: Can the T70P perform lifting operations?
Answer: Yes. With the appropriate lifting system, it supports payloads of up to 65 kg, subject to operating conditions and local regulations.
Question: What is Safety System 3.0?
Answer: Safety System 3.0 combines millimeter-wave radar and a Tri-Vision system to support obstacle sensing, terrain awareness and intelligent route selection.
Question: Does the DJI Agras T70P support RTK?
Answer: Yes. RTK positioning supports centimeter-level accuracy for field mapping and agricultural missions.
Question: What is the maximum operating speed?
Answer: The DJI Agras T70P supports an operating speed of up to 20 m/s under specified conditions.
Question: Are batteries and charging equipment included?
Answer: Included equipment depends on the selected package. Our team confirms the aircraft, battery, charger and accessory configuration before quote.
Question: Is training included?
Answer: Commissioning and operator training options can be added to the package.
Question: Can it be configured for my operation?
Answer: Yes. Our team can configure the spraying, spreading, lifting, battery, charging and RTK package for your operation.
Comparison
The DJI Agras T70P is designed for professional operators who need more capacity than the T50 while retaining a more compact platform than the flagship T100.
Compared with the DJI Agras T50, the T70P provides a larger 70 L spray tank, higher spray flow rates, a 100 L spreading system and optional lifting capability of up to 65 kg.
Compared with the DJI Agras T100, the T70P offers lower maximum capacity but may be easier to transport and integrate into operations that do not require the T100’s 100 L spray tank.
The DJI Agras T25P is suited to smaller fields, orchards and compact operations.
The DJI Agras T50 provides a balance of mobility and professional spraying capacity.
The DJI Agras T70P is designed for large farms and commercial applicators requiring higher throughput.
The DJI Agras T100 provides maximum capacity for the largest agricultural operations.
In The Box
DJI Agras T70P aircraft
70 L spraying system
Standard centrifugal sprinklers
Remote controller
Standard aircraft accessories
Propellers and tools
Product documentation
Spec Sheet
Model: DJI Agras T70P
Spray tank: 70 L
Standard spray flow: Up to 30 L/min
Maximum spray flow: Up to 40 L/min with optional four-sprinkler configuration
Spreading tank: 100 L
Maximum spreading payload: Up to 70 kg
Maximum lifting payload: Up to 65 kg
Maximum operating speed: Up to 20 m/s
Safety system: DJI Safety System 3.0
Obstacle sensing: Millimeter-wave radar and Tri-Vision system
Terrain following: Supported
RTK: Supported
RTK positioning accuracy: ±10 cm horizontal and vertical
Maximum configurable flight radius: 2 km
Compatible batteries: DJI DB1580 or DB2160 Intelligent Flight Battery
Flight time: Mission, payload, battery and environmental conditions dependent
Resources
DJI Agras T70P product documentation
DJI Agras T70P specifications
DJI Agras T70P user manual
DJI Agras T70P safety guidelines
DJI Agras T70P quick start guide
DJI Agras T70P spreading system documentation
DJI Agras T70P lifting system documentation
DJI T70P mist nozzle documentation
DJI DB1580 intelligent flight battery guidance
DJI DB2160 intelligent flight battery guidance
DJI C12000 Intelligent Power Supply documentation
DJI D14000iE generator documentation
DJI D-RTK 3 AG documentation
FAA drone operational guidance
FAA Part 107 compliance information
FAA Part 137 agricultural aircraft operations guidance
State pesticide applicator licensing resources
Agricultural application compliance information
Why choose the DJI Agras T70P?
- High-capacity spraying: The 70 L spray tank reduces refill frequency during large agricultural missions.
- Professional spray output: Up to 30 L/min standard flow and up to 40 L/min with the optional four-sprinkler configuration.
- Three operational modes: Supports spraying, spreading and specialized lifting applications.
- Advanced safety awareness: Safety System 3.0 combines millimeter-wave radar and Tri-Vision sensing.
- High field productivity: Maximum operating speeds of up to 20 m/s support demanding commercial operations.
- Built for U.S. operations: Suitable for large farms, commercial applicators, orchards, vineyards and specialty agriculture.
U.S. agricultural use cases
High-throughput crop spraying
- High-acreage crop protection and foliar feeding.
- Liquid fertilizer and targeted nutrient applications.
- Precision field spraying with RTK flight lines.
- Commercial application jobs requiring high flow and fewer refill stops.
- Spot-treatment of problem areas without heavy ground equipment.
Spreading, lifting & specialty work
- Granular fertilizer and compatible seed spreading.
- Orchards, vineyards and specialty crop applications.
- Pasture, ranch and cover crop operations.
- Agricultural lifting tasks using the compatible lifting system.
- Hard-to-reach, muddy or waterlogged agricultural areas.
Always follow product labels, drift-reduction best practices, FAA requirements and all applicable federal, state and local regulations. Agricultural dispensing and lifting operations may require additional approvals, operating limitations and pesticide applicator licensing.
Always follow product labels, drift-reduction best practices, FAA requirements and all applicable federal, state and local regulations. Agricultural dispensing and lifting operations may require additional approvals, operating limitations and pesticide applicator licensing.
- Aircraft setup: Aircraft activation, controller linking, firmware checks and system configuration.
- RTK setup: Positioning configuration, base station or network RTK setup and field accuracy checks.
- Flight skills: Takeoff, landing, route operations and safe emergency procedures.
- Mission planning: Field boundaries, application rates, flight lines and obstacle mapping.
- Spraying setup: Pump checks, flow calibration, sprinkler configuration and tank procedures.
- Spreading setup: Hopper configuration, material settings and spreading calibration.
- Lifting setup: Load attachment, weight limits, route planning and emergency procedures.
- Care & maintenance: System flushing, sprinkler cleaning, component inspection and battery storage procedures.
What you’ll need
- FAA compliance: Appropriate remote pilot certification, aircraft registration and required operational approvals.
- Agricultural authorization: Applicable FAA Part 137 approval and state pesticide applicator licensing when dispensing agricultural materials.
- Battery package: Compatible DJI DB1580 or DB2160 intelligent flight batteries selected for your required workflow.
- Charging system: Compatible DJI power supply, generator or suitable high-output electrical service.
- Insurance: Appropriate commercial drone and agricultural application insurance.
- Field setup: Water supply or nurse tank, mixing equipment, PPE and spill response kit.
- Transport: A suitable vehicle or trailer for the aircraft, batteries and application equipment.
Request a quote for DJI Agras T70P Agricultural Drone.
Tell us how you plan to use this drone and our team will confirm configuration, availability, delivery and pricing.
